Tube de chaudière de marinage de soudure d'acier inoxydable pour l'échangeur de chaleur
Product Details
| Catégorie en acier: | T1 D'ASME SA213, T11, T12, T2, T22, T23, T5, T9, T91, T92 | Surface: | Anneal&Pickling |
|---|---|---|---|
| Application: | échangeur de boiler&heat, énergie, produit pétrochimique, exploitation, nourriture, papier, gaz et i | Inspection de tiers: | LA BV, GV |
| Matériel: | Acier au carbone, acier inoxydable | Port: | Changhaï |
| Mettre en évidence |
Tube de chaudière de marinage d'acier inoxydable,Tube de chaudière de marinage d'échangeur de chaleur,Tube de chaudière d'acier inoxydable d'ASTM A269 |
||
Product Description
Tuyauterie de roulement de soudure de tube de chaudière d'acier inoxydable pour l'échangeur de chaleur
Introduction de production
Tuyau d'acier de ferrite sans couture d'alliage d'ASTM A335 pour la haute température
| Propriétés mécaniques | ||||||
| Catégorie | Résistance à la traction (MPA) | Limite conventionnelle d'élasticité (MPA) | Élongation (%) | Énergie d'impact (J) | Dureté | |
| P11 | ≥ 415 | ≥ 205 | ≥ 22 | ≥ 35 | ≤ 163HB | |
| P12 | ≥ 415 | ≥ 220 | ≥ 22 | ≥ 35 | ≤ 163HB | |
| P22 | ≥ 415 | ≥ 205 | ≥ 22 | ≥ 35 | ≤ 163HB | |
| P5 | ≥ 415 | ≥ 205 | ≥ 22 | ≥ 35 | ≤ 187HB | |
| P91 | 585~760 | ≥ 415 | ≥ 20 | ≥ 35 | ≤ 250HB | |
| P92 | ≥ 620 | ≥ 440 | ≥ 20 | ≥ 35 | 250HB | |
D'AUTRES matériaux :
ASTM A199 T9, T11, T22
T1 D'ASTM A209, T1A, T1B
ASTM A210 C
T1 D'ASTM A250
ASTM A369 FP1, FP2, FP12, FP22, FP9
PP5 D'ASTM A389
JIS G3455 STS49
JIS 3456 STPT49
JIS G3458 STPA12, STPA 22, STPA23, STPA24, STPA25, STPA26
JIS G3462 STBA12, 13, STBA20, STBA22, STBA23, STBA24, STBA25, STBA26
JIS G3464 STBL39
SEW610 10CrMo910
DIN 1629 St52.4, St52
DIN 17175 15Mo3, 13CrMo44, 12CrMo195
GB9948 16Mn, 15MnV, 16Mo, 12CrMo, 15CrMo, 12Cr1MOV, Cr2Mo, 10MoWVNB, Cr5Mo, Cr9Mo,
GB/T8162/8163 Q345, 20Cr, 40Cr, 20CrMo, 25CrMo, 30CrMo, 35CrMo, 34Mn2V, 42CrMo, WB36
(15NICUMOB5) et 12Cr2MoWVTiB (R102)
GB5310 12CrMoG, 15CrMoG, 12Cr1MoVG
GB/T 17396 27SiMn
GB18248 37Mn, 34Mn2V, 35CrMn, 34CrMo4
Type : Sans couture et soudé
Taille :
Diamètre extérieur : 6mm~1420mm
Épaisseur de paroi : 1mm~60mm
Longueur : 12m, 11.8m, 6m, 5.8m ou comme condition. Maximum : 25m.pc
Product Highlights
Tuyauterie de roulement de soudure de tube de chaudière d'acier inoxydable pour l'échangeur de chaleur Introduction de production Norme ASTM A269 Surface Polonais, recuisant, marinage, lumineux Matériel 200 séries, 300 séries, 400 séries Taille (tube rond) Épaisseur de paroi : 1mm-150mm OD : 6mm...
Le charbon adapté aux besoins du client de soudure à haute fréquence a mis le feu à des pièces de chaudière à vapeur empilent la bobine d'économiseur
High Frequency Welding Customized Coal Fired Steam Boiler Parts Stack Economizer Coil Boiler economizer Boiler Economizer is the energy improving device that helps to reduce the cost of operation by saving the fuel. The economizer in Boiler tends to make the system more energy efficient. In boilers, economizers are generally designed to exchange heat with the fluid, generally water. The exhaust from the boilers is generally in the temperature range of 200°C – 250°C, so there
Tube d'aileron de soudure à haute fréquence de spirale de chaudière pour le transfert de chaleur d'économiseur
High Frequency Welding Boiler Spiral Fin Tube For Economizer Heat Transfer Boiler economizer Boiler Economizer is the energy improving device that helps to reduce the cost of operation by saving the fuel. The economizer in Boiler tends to make the system more energy efficient. In boilers, economizers are generally designed to exchange heat with the fluid, generally water. The exhaust from the boilers is generally in the temperature range of 200°C – 250°C, so there are a huge
Type de l'échangeur de chaleur H tube de pièces de chaudière pour l'usine de service de centrale
High Efficient Heat Exchang H Type High Temperature Resistance Boiler Parts For Utility/Power Station Plant Product Introduce H-fin Tubes have two steel discs,with fluorescent tubes symmetrically welded together to form fins(fins of butterfly piece)creating a shape that looks somewhat like the letter"H",creating an efficient energy saving, extension heating surface.H-fin Tubes also have a high rate of fusion welds and weld tensile strength.H-fin Tube is assembled with the H
Tube d'aileron extérieur de chaudière de chauffage d'extension pour la chaudière industrielle de centrale
Energy Saving Extension Heating Surface Boiler Fin Tube For Industrial Power Plant Boiler Product Description H-fin Tubes have two steel discs,with fluorescent tubes symmetrically welded together to form fins(fins of butterfly piece)creating a shape that looks somewhat like the letter"H",creating an efficient energy saving, extension heating surface. H-fin Tubes also have a high rate of fusion welds and weld tensile strength.H-fin Tube is assembled with the H economizer,
